Svelte Shy Header: Peekaboo Sticky Header with CSS # Svelte Shy Header: Peekaboo Sticky Header with CSS #

Original HTML / CSS / JavaScript Solution #

Jake’s full solution is on CodePen  and uses plain HTML, CSS and JavaScript. Here is a summary:


<div class="header-shifter"></div>
<div class="header">Header</div>
<p>First paragraph</p>
<p>Paragraph</p>
<p>Paragraph</p>
<p>Paragraph</p>
<p>Paragraph</p>




body {
  margin: 0;
}
.header {
  position: relative;
  background: blue;
  color: white;
  padding: 20px;
}




// This is adaptation of https://jsbin.com/mamisar/edit?html,css,js,output
// By https://twitter.com/flackrw

const header = document.querySelector('.header');
const headerShifter = document.querySelector('.header-shifter');

header.style.position = 'sticky';
header.style.top = 'calc(var(--computed-height) * -1 - 1px)';
header.style.bottom = 'calc(100% - var(--computed-height))';

function fixHeaderoffset() {
  const { height } = header.getBoundingClientRect();
  header.style.setProperty('--computed-height', height + 'px');

  const y = Math.min(
    header.offsetTop,
    document.documentElement.scrollHeight - innerHeight - height
  );
  headerShifter.style.height = y + 'px';
  header.style.marginBottom = -y + 'px';
}

addEventListener('scroll', () => fixHeaderoffset());
addEventListener('resize', () => fixHeaderoffset());
fixHeaderoffset();



🔫 Svelte Shy Header: Sveltification Plan of Action #

Here’s my initial thinking on the Sveltification process:

• you can easily bind a JavaScript variable to an element’s height with Svelte’s dimension bindings,
• Svelte has some nice syntactic sugar for adding event listeners. We will try to work these in for the scroll and resize events,
• there’s also a Svelte way to bind an element to a JavaScript variable. This will simplify any element style updates we keep in the JavaScript code. We will try to move some of them down to the element using style directives.

Enough talk, time for some action.

🧱 Svelte Shy Header: Code Along #

If you are new to Svelte, hopefully this little project can provide a gentle introduction. Here’s how you can spin up a new project. Start by running these commands in the Terminal:


pnpm create svelte@latest svelte-shy-header
cd svelte-shy-header
pnpm install
pnpm install @fontsource/playfair-display # installs a font used later for self-hosting
pnpm dev



You will get some options, choose a Skeleton project and whatever you like for the others. The last command will start up a dev server and spit out a URL you can paste into your browser. We will only create or change two files, so just paste the code in when we get to that point. Also, make sure you play with, breaking and repairing stuff, to understand better what it is doing!

🏠 Home Page #

I thought, why not throw in a background CSS pattern? I opted for customizing the Colorful Stingrays pattern from www.svgbackgrounds.com  . Here is the full code for the home page (replace existing content in src/routes/+page.svelte if you are coding along):


1 <script>
2 	import Header from '$lib/components/Header.svelte';
3 	import '@fontsource/playfair-display/latin.css';
4 </script>
5
6 <Header />
7 <main class="container" />
8
9 <style>
10 	:global(body) {
11 		margin: 0;
12 		font-family: Playfair Display;
13 	}
14 	:global(:after, :before) {
15 		box-sizing: border-box;
16 	}
17 	:global(:root) {
18 		--font-size-6: 3.052rem;
19
20 		--font-weight-bold: 700;
21
22 		--max-width-full: 100%;
23 		--spacing-6: 1.5rem;
24
25 		--colour-brand: hsl(19 97% 51%);
26 		--colour-dark: hsl(345 6% 13%);
27 	}
28 	.container {
29 		height: 500vh;
30 		width: var(--max-width-full);
31
32 		/* CREDIT: https://www.svgbackgrounds.com/ */
33 		background-color: #3d315b;
35 	}
36 </style>



This is a typical Svelte file with three sections: script tag where we run the JavaScript Code, the Svelte markup, then the style tag. We place the Header in its own component file (imported in line 2). This makes it easier to recycle it for use on other pages. On top, you can easily create a Svelte component library, letting you share the code between your other Svelte projects.

🙈 Svelte Shy Header Component #

If coding along, create a src/lib/components/Header.svelte file (you will need to create a couple of new folders). That is the file we look at now. This file will eventually have the three sections we have in the home page, but we will start with the middle section:


1 <svelte:window on:scroll={fixHeaderOffset} on:resize={fixHeaderOffset} />
2
3 <div style:height="{headerShifterHeight}px" class="header-shifter" />
4 <div
5 	bind:this={header}
6 	bind:clientHeight={headerHeight}
7 	style:margin-bottom="-{headerShifterHeight}px"
8 	class="header"
9 >
10 	<header class="wrapper">☺️ Svelte Shy Header 🙈</header>
11 </div>



In line 1, we add the event listeners for scroll and resize events, but the Svelte way! fixHeaderOffset is the function we will invoke on these events. We will define it later.

Next, in like 3, we have the header-shifter div. We keep the original class name, but also add:


style:height="{headerShifterHeight}px"



As you might guess, we are setting the element’s height here, using CSS. This is a Svelte style directive. In place of height you can have any regular CSS property or even a custom CSS property (often called CSS variable). headerShifterHeight is a number variable which we will define in the script tag. The px is just to add expected units for valid CSS. An alternative would have been to write something like this, making use of the element’s style attribute and JavaScript template strings:


<!-- LESS OPTIMAL -->
<div style={`height=${headerShifterHeight}px`} class="header-shifter" />



It is Svelte best practice to avoid this, just because, using the original code, the Svelte compiler optimizes the output. It will only update styles on the element if headerShifterHeight changes.

header Element #

Let’s see the header div now (lines 4 – 9 above). Here it is again:


<div
 	bind:this={header}
 	bind:clientHeight={headerHeight}
 	style:margin-bottom="-{headerShifterHeight}px"
 	class="header"
 >



We just saw a style directive, and the class attribute is nothing new. That leaves the two bind statements. The first bind:this={header} is another Sveltism. This lets us bind the element itself to the JavaScript variable header. That saves us writing out a query selector when we get to writing the script tag. It’s just syntactic sugar making the code a little cleaner.

The second bind directive it where we link the header’s height to the headerHeight JavaScript variable. This will save us calling getBoundingClientRect later in the script tag.

💄 Svelte Style #

Paste this code in if you are coding along


13 <style>
14 	.header-shifter {
15 		background-color: var(--colour-dark);
16 	}
17 	.header {
18 		--_computed-height: var(--computed-height, 165px);
19 		position: relative;
20 		background: var(--colour-dark);
21 		color: var(--colour-brand);
22 		padding: var(--spacing-6);
23 	}
24 	.wrapper {
25 		width: var(--max-width-full);
26 		margin: var(--spacing-6) auto;
27 		max-width: var(--max-width-full);
28 		font-size: var(--font-size-6);
29 		font-weight: var(--font-weight-bold);
30 		text-align: center;
31 	}
32 </style>



We are adding a touch more style vs. the original version, but not really changing anything fundamentally. The main change is the --_computed-height custom CSS property in line 18. The CSS custom property spec lets us specify a fallback value as a second argument. CSS will use this, second, value if --computed-height is not set. You will notice we do not set it anywhere here in the CSS. As in the original solution, we set it using JavaScript. However, if the user has JavaScript disabled in their browser, we can rely on the fallback value we provide here. This is not strictly necessary (the property is only used in styles added by JavaScript), but provides a nice demo of how you can define defaults. Props to Geoff Rich for this technique  .

🐇 Svelte Shy Header: Java Script #

Finally, we can see the much trailed script tag! Once again, paste this in (right at the top of src/lib/components/Header.svelte) if you are coding along.


1 <script lang="ts">
2 	/* This is code is based on an adaptation by https://twitter.com/jaffathecake of
3 	https://jsbin.com/mamisar/edit?html,css,js,output By https://twitter.com/flackrw
4 	*/
5
6 	import { onMount } from 'svelte';
7
8 	let header: HTMLDivElement;
9 	let headerHeight: number;
10 	let headerShifterHeight = 0;
11
12 	function fixHeaderOffset() {
13 		header.style.setProperty('--computed-height', `${headerHeight}px`);
14
15 		headerShifterHeight =
16 			Math.min(
17 				header.offsetTop,
18 				document.documentElement.scrollHeight - window.innerHeight - headerHeight,
19 			) - 1;
20 	}
21
22 	onMount(() => {
23 		header.style.position = 'sticky';
24 		header.style.top = 'calc(var(--_computed-height) * -1 - 1px)';
25 		header.style.bottom = 'calc(100% - var(--_computed-height))';
26 		fixHeaderOffset();
27 	});
28 </script>



I should have mentioned I am using TypeScript. Drop the lang=ts and type annotations (:HTMLDivElement & :number) in lines 13, 20 and 21 if you opted for JavaScript instead.

Let’s see what we have. In lines 8 and 9 we declare the variables which we bound in the template code. Then in line 10 we declare and initialize the headerShifterHeight which we also used in the markup. Just by using let here, we make the variable reactive. This means when it changes, Svelte will automatically update the style directives (as well as anything else linked) we added earlier.

The fixHeaderOffset function in the original implementation remains, though we have a few differences. We got rid of the getBoundingClientRect call to get the header height, as we now have the value bound to headerHeight by Svelte. We renamed y to headerShifterHeight, just so the template code is a little clearer. Then, remember we use style directives to set the height on the header-shifter element and bottom margin on the header element, so removed those two lines.

Svelte onMount #

Finally, all we have left is onMount. This is a Svelte lifecycle method. An alternative it to use Svelte actions. We explore both in the tutorial on creating a Svelte video blog  , where we use these in lazy loading video and images.

We set the CSS style props here, instead of using style directives just because, we will not need them defined if the user has JavaScript disabled. In this instance, we want a regular position: relative header, rather than a sticky one managed in JavaScript. Since the onMount function will not load with JavaScript disabled, the CSS override here on header.style.position is only set with JavaScript enabled.

The top and bottom CSS properties are only relevant when JavaScript is enabled (we use relative positioning otherwise). Taking that into account, we set those two properties in onMount rather than using style directives. Note how we use --_computed-height instead of --computed-height. This is because, as we mentioned above, the former will have a default value, available before we first calculate and set --computed-height.

Finally, we put the fixHeaderOffset call in onMount because we need to access the bound JavaScript variables (header and headerHeight) when the function is invoked. These are only available once we mount the component. So placing the initial fixHeaderOffset call here avoids calling it when those variable are still undefined.

🙌🏽 Svelte Shy Header: Wrapup #

In this Svelte shy header post. We saw some useful Svelte methods and how they relate to those you might see in plain HTML / CSS / JavaScript sites. In particular, we have touched on:

• how to use Svelte style directives for component styling and when another approach might be preferred;
• full code for implementing a Svelte shy header as a reusable component; and
• how to bind component dimensions to JavaScript variables with Svelte.

As a next step, you might consider following one of the tutorials to learn more about Svelte. If you already know the basics, also try adding this stick header to a Svelte component library. You might also want to take CSS custom properties to the next level, setting them in Svelte actions. Let me know what you end up creating. You can drop a comment below or reach out for a chat on Element  as well as Twitter @mention

You can see the full code for this Svelte shy header project, in all its glory in the Rodney Lab Git Hub repo  .

🏁 Svelte Shy Header: Summary #

Is it always better to use Svelte style directives instead of setting styles in JavaScript? #

Svelte style directives let you add styling directly to an element. They can add optimizations over using a `style` attribute on the element. Normally, you only use style directives when the CSS property you have is dynamic. As an example, the element changes colour when something changes in JavaScript code. Generally, you will benefit from Svelte in-build optimizations by using style directives instead of setting style on the element in JavaScript directly. One time you might want to use JavaScript, though, is if you need to style differently when JavaScript is enabled vs. when the user has disabled JavaScript. We saw an example of this, setting position to `sticky` (from `relative`) on a peekaboo header with JavaScript enabled.

Can you set default CSS custom property values in Svelte? #

We saw an example where we wanted to set a custom property in Svelte code and use that property independently of CSS. With JavaScript disabled, the property would be undefined. We saw a technique which let us set a default. The CSS property we wanted to use was --computed-height. By introducing a second CSS property `--_computed-height` we could set a default. We did this by using the CSS feature which lets us set a fallback for custom properties, using an optional second argument. In our case, we set `--_computed-height: var(--computed-height, 165px);`. Now, once we set `--computed-height` in our JavaScript code, `--_computed-height` would take on that value. However, while `--computed-height` remains undefined, `--_computed-height` gets 165px, the default. We saw if we reference `--_computed-height` in our code, we will never get an undefined value back.

How can you access element dimension in Svelte? #

Svelte lets you bind JavaScript values to element dimensions as well as the elements themselves. If, for example, we wanted to use the height of an element in JavaScript, we can use Svelte’s in-built syntactic sugar. First, we add `bind:clientHeight={headerHeight}` amid the elements attributes in its markup. This sets the JavaScript variable `headerHeight` to the element height. To finish off, we just need to declare the variable in our script tag: `let headerHeight;`. That’s all there is to it. You can set width too. There is a further shortcut. For that to work, though, the JavaScript variable needs to be named `clientHeight`. In this case, we just add `bind:clientHeight` on the element.
